Driving type
6*4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
6*4
Wheelbase(mm)
3425+1400
Max. Speed/(km/h)
90km/h
Usage Scenario
Engineering construction, Logistics transportation
MAIN PARAMETER
| MODEL | SX42555V344 | |
| Driver position | Left Hand | |
| Driving type | 6*4 | |
| Wheelbase/(mm) | 3425+1400 | |
| Max. Speed/(km/h) | 90km/h | |
Engine
| Brand | WEICHAI |
| Model | WP12.430E201 | |
| Emission Standard | EURO II | |
| Rated output power/（PS） | 316KW/430HP | |
| Displacement(L) | 11.596L | |
Transmission
| Brand | FAST |
| Model | 12JSDX240K | |
Front axle | Brand | HANDE |
| Model | MAN 9.5T | |
| Rear axle | Brand | /HANDE |
| Model | 16T MAN double reduction driving axle Speed ratio: 5.262 | |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 850*300(8+7) | |
| Suspension | Front and rear multi-leaf spring Two main flims+two horse riding | |
| Fuel tank/ | 460L+260L Aluminum alloy | |
| Wheels and tires | 12.00R20 （9.0） | |
| Brakes | Running brake:Dual circuit compressed air brake | |
| Parking brake:Air discharging with spring control | ||
| Auxiliary brake:Engine exhaust brake | ||
| Cabin | X3000 extended flat top cab with roof deflector, air master seat, four point air suspension cab, electric heated rearview mirror, electrically controlled automatic temperature control air conditioning, electric window rocking machine, electric flipping, metal bumper with light protection net, three-level boarding pedal, central locking (dual remote control), multifunctional steering wheel, oil bath air filter (with upper and lower protection), ordinary exhaust, rear axle stabilizer bar, reinforced 90 # saddle, tail light protection grille 180Ah low-temperature maintenance free battery, SHACMAN Telematics (with screen but without terminal), cab with sunroof and rear window, reserved air blower interface in the cab, independent water and air heating, upper armrest, SHACMAN logo, all English logo, chrome plated Malii logo on both sides of the doors, radiator oil pan protection plate, enlarged operating platform (VI), quick plug trailer air pipe joint, flat connection plate, simple spare tire rack, 2KG fire extinguisher Inverter power supply, telescopic shaft control, metal mudguard, low-temperature pipe harness, non electrified heating oil sensor, cancellation of fuel anti-theft alarm function | |
* Description:
1. Terms of payment: T/T, 30% deposit, balance before delivery from factory.
2. Delivery at China port period: 55 working days after advance payment.
3. Vehicle warranty period: 24 months from the date of bill of lading.
