Driving type
6X6
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
6X6
Wheelbase(mm)
3775+1400
Max. Speed/(km/h)
80km/h
PRODUCT DETAILS
| MODEL | SX4255JV385 | |
| Driver position | Left Hand | |
| Driving type | 6*6 | |
| Wheelbase(mm) | 3775+1400 | |
| Max. Speed(km/h) | 90km/h | |
Engine | Brand | WEICHAI |
| Model | WP12.430E201 | |
| Emission Standard | EURO II | |
| Rated output power（PS） | 316KW/430HP | |
| Displacement(L) | 11.596L | |
| Transmission | Brand | FAST |
| Model | 12JSD200T-B | |
| Front axle | Brand | HANDE |
| Model | MAN 9.T | |
| Rear axle | Brand | HANDE |
| Model | 16T MAN double driving axle Speed ratio ：4.769 | |
| Clutch | ￠430 diaphragm clutch￠430 | |
| Steering | ZF technology/ ZF | |
| Frame | 850×300（8+7） | |
| Suspension | Front and rear multi-leaf spring ,four main films+Four horse riding前后多片簧，四主片+四骑马 | |
| Fuel tank | 700L Aluminum fuel tank | |
| Wheels and tires | 14.00R20 | |
| Brakes | Running brake:Dual circuit compressed air brake | |
| Parking brake:Air discharging with spring control | ||
| Auxiliary brake:Engine exhaust brake | ||
| Cabin | F3000 extended flat top cab without roof deflector, air main seat, four point hydraulic suspension, ordinary rearview mirror, electrically controlled automatic constant temperature air conditioning, electric window machine, manual flipping, metal bumper with light protection net, three-level boarding pedal, oil bath air filter, ordinary exhaust, water tank protection grille, oil pan protection grille, reinforced 90 saddle, split mudguard, tail light protection grille, 165Ah maintenance free battery, 2 hazard warning lights, SHACMAN logo, full French logo, installation of a long-lasting coarse filter, battery box anti-theft, fuel system anti-theft | |
| Upbody | ||
