Driving type
6*4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
6*4
Wheelbase(mm)
3175+1400
Max. Speed/(km/h)
90km/h
Usage Scenario
Engineering construction, Logistics transportation
MAIN PARAMETER
| MODEL | SX4255JT324 | |
| Driver position | Left Hand | |
| Driving type | 6*4 | |
| Wheelbase/(mm) | 3175+1400 | |
| Max. Speed/(km/h) | 90km/h | |
Engine
| Brand | WEICHAI |
| Model | WP10.380E22 | |
| Emission Standard | EURO II | |
| Rated output power/（PS） | 279KW/380HP | |
| Displacement(L) | 9.726L | |
Transmission
| Brand | FAST |
| Model | 10JSD160 | |
| Front axle | Brand | HANDE |
| Model | MAN 7.5T | |
| Rear axle | Brand | HANDE |
| Model | 13T MAN double reduction driving axleSpeed ratio: 4.769 | |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 850*300（8+5） | |
| Suspension | Front and rear multi-leaf spring，four main films+four horse riding | |
| Fuel tank | 380L | |
| Wheels and tires | 12.00R20 | |
| Brakes | Running brake:Dual circuit compressed air brake | |
| Parking brake:Air discharging with spring control | ||
| Auxiliary brake:Engine exhaust brake | ||
| Cabin | F3000 extended flat top cab without top air deflector, hydraulic main seat, four point hydraulic suspension, ordinary rearview mirror, single refrigeration air conditioning, manual window rocking machine, manual flipping, metal bumper with light protection net, three-level boarding pedal, oil bath air filter, ordinary exhaust, water tank protection grille, reinforced 90 saddle, split type mudguard, tail light protection grille, 165Ah maintenance free battery, 2 hazard warning lights, SHACMAN logo, full English logo, iron air storage tank, 2KG fire extinguisher, reverse buzzer, telescopic shaft control, fuel tank cover anti-theft, battery box anti-theft, X3000 air intake flat pipe | |
* Description:
1. Terms of payment: T/T, 30% deposit, balance before delivery from factory.
2. Delivery at China port period: 55 working days after advance payment.
3. Vehicle warranty period: 12 months from the date of bill of lading.
