Driving type
4x2
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
4x2
Wheelbase(mm)
4500
Max. Speed/(km/h)
80km/h
PRODUCT DETAILS
| MODEL | SX12588K43L | |
| Driver position | 左舵 Left Hand | |
| Driving type | 4*2 | |
| Wheelbase(mm) | 4500 | |
| Max. Speed(km/h) | 90km/h | |
Engine | Brand | WEICHAI |
| Model | WP7.240E51 | |
| Emission Standard | EURO V | |
| Rated output power（PS） | 240HP/176KW | |
| Displacement(L) | 7.14L | |
| Transmission | Brand/品牌 | FAST/法士特 |
| Model/型号 | 8JS105 | |
| Front axle/前轴 | Brand/品牌 | 汉德牌/HANDE |
| Model/型号 | 4.8T鼓式 | |
| Rear axle/后桥 | Brand/品牌 | 汉德牌/HANDE |
| Model/型号 | 10T MAN双级桥 double reduction driving axle Speed ratio 速比：4.625 | |
| Clutch/离合器 | ￠430 diaphragm clutch￠430离合器 | |
| Steering/转向机 | ZF technology/ ZF技术 | |
| Frame/车架 | 870x250(7+4) | |
| Suspension | Front and rear multi-leaf 前后多片簧 | |
| Fuel tank | 200L Iron fuel tank | |
| Wheels and tires | 10.00R20 6+1 | |
| Brakes | Running brake:Dual circuit compressed air brake | |
| Parking brake:Air discharging with spring control | ||
| Auxiliary brake:Engine exhaust brake | ||
| Cabin | ||
| Electric air conditioning, electric window shaker, LED daytime running lights, central locking (dual remote control), front fixed and rear hydraulic suspension, 135Ah maintenance-free battery, exhaust pipe rear with fireproof cap, spare tire rack, aluminum alloy air reservoir, hydraulic main seat, with third seat, manual flipping, SHACMAN logo, all English logo | ||
| Upbody | 10 cube | |
