Driving type
6*4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
6*4
Wheelbase(mm)
4275+1400
Max. Speed/(km/h)
80km/h
Usage Scenario
Engineering construction, Logistics transportation
MAIN PARAMETER
| MODEL | SX5255GSSDR434 | |
| Driver position | Left Hand | |
| Driving type | 6*4 | |
| Wheelbase/(mm) | 4275+1400 | |
| Max. Speed/(km/h) | 80km/h | |
Engine
| Brand | WEICHAI |
| Model | WP10.340E22 | |
| Emission Standard | EURO II | |
| Rated output power/（PS） | 340 | |
| Displacement(L) | 9.726L | |
Transmission
| Brand | FAST |
| Model | 9_RTD11509C--QH50 | |
| Front axle | Brand | HANDE |
| Model | MAN 7.5T | |
| Rear axle | Brand | HANDE |
| Model | 13T MAN double reduction driving axle Speed ratio: 5.266 | |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 850x300(8+5) | |
| Suspension | Front and rear multi-leaf spring two main flims+two horse riding | |
| Fuel tank | 400L Aluminum alloy | |
| Wheels and tires | 12R22.5 | |
| Brakes | Running brake: Dual circuit compressed air brake | |
| Parking brake: Air discharging with spring control | ||
| Auxiliary brake: Engine exhaust brake | ||
| Cabin | Air main seat, four point air suspension cab, electrically controlled automatic constant temperature air conditioning, electric window shaking machine, manual flipping, ordinary air filter, flat mounting plate, metal bumper, hinged boarding pedal, split mudguard, 165Ah maintenance battery, SHACMAN identification, full English identification | |
* Description:
1. Terms of payment: T/T, 30% deposit, balance before delivery from factory.
2. Delivery at China port period: 45 working days after advance payment.
3. Vehicle warranty period: 24 months from the date of bill of lading.
