Driving type
4*2
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
4*2
Wheelbase(mm)
4500
Max. Speed/(km/h)
80km/h
Usage Scenario
Engineering construction, Logistics transportation
MAIN PARAMETER
| MODEL | SX5185GYY8J451 | |
| Driver position | Left Hand | |
| Driving type | 4*2 | |
| Wheelbase/(mm) | 4500 | |
| Max. Speed/(km/h) | 80km/h | |
Engine
| Brand | WEICHAI/ |
| Model | WP6.210E32 | |
| Emission Standard | EURO II | |
| Rated output power/（PS） | 154KW/210HP | |
| Displacement(L) | 6.75L | |
Transmission
| Brand | FAST |
| Model | 8JS85TM+QD40J | |
| Front axle | Brand | HANDE |
| Model | MAN 4.8T | |
| Rear axle | Brand | HANDE |
| Model | 10T MAN double reduction driving axle Speed ratio: 4.625 | |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 870x250(7+4) | |
| Suspension | Front and rear multi-leaf spring | |
| Fuel tank | 200L | |
| Wheels and tires | 10.00R20 | |
| Brakes | Running brake: Dual circuit compressed air brake | |
| Parking brake: Air discharging with spring control | ||
| Auxiliary brake: Engine exhaust brake | ||
| Cabin | Electric air conditioning, electric window shaker, LED daytime running lights, central locking (dual remote control), front fixed and rear hydraulic suspension, 135Ah maintenance free battery, soft shaft operation, rear exhaust pipe with fireproof cap, spare tire rack, aluminum alloy air reservoir, hydraulic main seat, with third seat, manual flipping, SHACMAN logo, all English logo | |
| Upbody | 5 | |
* Description:
1. Terms of payment: T/T, 30% deposit, balance before delivery from factory.
2. Delivery at China port period: 55 working days after advance payment.
3. Vehicle warranty period: 12 months from the date of bill of lading.
