Driving type
8x4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
8x4
Wheelbase(mm)
1800+3775+1400
Max. Speed/(km/h)
75km/h
PRODUCT DETAILS
| MODEL/车型 | SX33156V386C | |
| Driver position | Left Hand | |
| Driving type | 8*4 | |
| Wheelbase(mm) | 1800+3775+1400 | |
| Max. Speed(km/h) | 75km/h | |
Engine/发动机 | Brand | CUMMINS |
| Model/型号 | ISME420 30 | |
| Emission Standard/排放 | EURO III | |
| Rated output power/功率（PS） | 308KW/420HP | |
| Displacement(L)/排量 | 10.8L | |
| Transmission/变速箱 | Brand/品牌 | FAST/法士特 |
| Model/型号 | 12JSD200T+铁壳+QH50 | |
| Front axle/前轴 | Brand/品牌 | 汉德牌/HANDE |
| Model/型号 | MAN 9.5T | |
| Rear axle/后桥 | Brand/品牌 | 汉德牌/HANDE |
| Model/型号 | 16T MAN双级减速桥 速比：5.262 | |
| Clutch/离合器 | ￠430 diaphragm clutch￠430离合器 | |
| Steering/转向机 | ZF technology/ ZF技术 | |
| Frame/车架 | 850x300(8+7) | |
| Suspension/悬架 | Front and rear multi-leaf spring, four main films+Four horse riding前后多片簧四主片+四骑马 | |
| Fuel tank/燃油箱 | 400L铝合金 Aluminum alloy | |
| Wheels and tires/轮胎 | 12.00R24 10+1 | |
| Brakes/制动 | Running brake:Dual circuit compressed air brake/行车制动 | |
| Parking brake:Air discharging with spring control | ||
| Auxiliary brake:Engine exhaust brake | ||
| Cabin/驾驶室 | ||
| X3000 medium length flat top cab without top air deflector, hydraulic main seat, four point hydraulic suspension, ordinary rearview mirror, electrically controlled automatic temperature control air conditioning, manual window rocking machine, manual flipping, metal bumper with light protection net, three-level boarding pedal, central locking (with remote control), oil bath air filter, ordinary exhaust, water tank protection grille, oil pan protection grille, tail light protection grille, 180Ah maintenance free battery, SHACMAN Telematics (without screen) 2 hazard warning lights, SHACMAN logo, full French logo, equipped with a long-lasting coarse filter, iron air reservoir, nut protective cap, TR 668 for front wheel, TR 918 for rear wheel and spare tire, reverse buzzer, anti-theft battery box, and anti-theft fuel tank cap | ||
| Upbody/上装 | 7600*2300*1500(mm) | |
