Driving type
8X4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
8X4
Wheelbase(mm)
1800+2975+1400
Max. Speed/(km/h)
70km/h
PRODUCT DETAILS
| MODEL | SX5315GJB6T306 | |
| Driver position | Left Hand/Right Hand | |
| Driving type | 8*4 | |
| Wheelbase(mm) | 1800+2975+1400 | |
| Max. Speed(km/h) | 75km/h | |
Engine | Brand | WEICHAI |
| Model | WP10.380E22+PTO | |
| Emission Standard | EURO II | |
| Rated output power（PS） | 279KW/380HP | |
| Displacement(L) | 9.726L | |
| Transmission | Brand | FAST |
| Model | 10JSD180 | |
| Front axle | Brand | HANDE |
| Model | MAN 9.5T | |
| Rear axle | Brand | HANDE |
| Model | 16T MAdouble speed reduction bridgeSpeed ratio：5.262 | |
| Clutch | ￠430 diaphragm clutch￠430 | |
| Steering | ZF technology/ ZF | |
| Frame | 850x300(8+7) | |
| Suspension | Front and rear multi-leaf spring four main flims+four horse riding | |
| Fuel tank | 300LAluminum alloy fuel tank | |
| Wheels and tires | 12.00R20 12+1 | |
| Brakes | Running brake:Dual circuit compressed air brake | |
| Parking brake:Air discharging with spring control | ||
| Auxiliary brake:Engine exhaust brake | ||
| Cabin | Hydraulic main seat, four-point hydraulic suspension cab, electronically controlled automatic constant temperature air conditioning, electric window shaker, manual flip, telescopic shaft operation, ordinary air filter, metal bumper, daytime running lights, hinged access pedal , 180Ah maintenance-free battery, spare tire rack, SHACMAN logo, full English logo, remote throttle controller shipped with the vehicle (only electronically controlled engine) | |
| Upbody | 16cube | |
