Driving type
6*4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
6*4
Wheelbase(mm)
3975+1400
Max. Speed/(km/h)
75km/h
Usage Scenario
Engineering construction, Logistics transportation
MAIN PARAMETER
| MODEL | SX5255GJBMV404C | |
| Driver position | Left Hand | |
| Driving type | 6*4 | |
| Wheelbase/(mm) | 3975+1400 | |
| Max. Speed/(km/h) | 75km/h | |
Engine
| Brand | CUMMINS |
| Model | ISME420 30 Jacob | |
| Emission Standard | EURO III | |
| Rated output power/（PS） | 308KW/420HP | |
| Displacement(L) | 10.8L | |
Transmission
| Brand | FAST |
| Model | 12JSD200T +PT0 | |
| Front axle | Brand | HANDE |
| Model | MAN 7.5T | |
| Rear axle | Brand | HANDE |
| Model | 16T MAN double reduction driving axle Speed ratio: 4.769 | |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 850x300(8+7) | |
| Suspension | Front and rear multi-leaf spring four main flims+four horse riding bolts | |
| Fuel tank | 360L Aluminum alloy | |
| Wheels and tires | 315/80 R22.5 10+1 | |
| Brakes | Running brake: Dual circuit compressed air brake | |
| Parking brake: Air discharging with spring control | ||
| Auxiliary brake: Engine exhaust brake | ||
| Cabin | H3000 standard cab without top air deflector, hydraulic main seat, four point hydraulic suspension, pole type rearview mirror, single cooling air conditioning, electric window rocking machine, manual flipping, metal bumper, secondary boarding pedal, ordinary air filter, ordinary exhaust, water tank protective grille, 165Ah maintenance free battery, with circular curtains, with rear window SHACMAN logo, full English logo, gold lettering, iron air reservoir, reverse buzzer, transmission telescopic shaft control, upper operating handle installed on the left side of the main seat, Jack Sail compressor, 32T jack | |
| Upbody | 10 | |
* Description:
1. Terms of payment: T/T, 30% deposit, balance before delivery from factory.
2. Delivery at China port period: 55 working days after advance payment.
3. Vehicle warranty period: 12 months from the date of bill of lading.
