Driving type
6*4
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Email: shacman@shacman-truck.com
Tel.: +86 135 7927 1170
Driving type
6*4
Wheelbase(mm)
3975+1400
Max. Speed/(km/h)
75km/h
Usage Scenario
Engineering construction, Logistics transportation
MAIN PARAMETER
| MODEL | SX5255GJBDV404C | |
| Driver position | Left Hand | |
| Driving type | 6*4 | |
| Wheelbase/(mm) | 3975+1400 | |
| Max. Speed/(km/h) | 75km/h | |
Engine
| Brand | CUMMINS |
| Model | ISME420 30 +PTO Jacob | |
| Emission Standard | EURO III | |
| Rated output power/（PS） | 308KW/420HP | |
| Displacement(L) | 10.8L | |
Transmission
| Brand | FAST |
| Model | 12JSD200T-B | |
| Front axle | Brand | HANDE |
| Model | MAN 7.5T | |
| Rear axle | Brand | HANDE |
| Model | 16T MAN double driving axle Speed ratio: 5.262 | |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 850x300(8+7) | |
| Suspension | Front and rear multi-leaf spring four main flims+four horse riding bolts | |
| Fuel tank | 300L Aluminum alloy | |
| Wheels and tires | 315/80 R22.5 10+1 | |
| Brakes | Running brake:Dual circuit compressed air brake | |
| Parking brake:Air discharging with spring control | ||
| Auxiliary brake:Engine exhaust brake | ||
| Cabin | Hydraulic main seat, four point hydraulic suspension cab, electrically controlled automatic constant temperature air conditioning, electric window rocking machine, manual flipping, ordinary air filter, metal bumper, hinged boarding pedal, 165Ah maintenance free battery, spare tire rack, SHACMAN logo, all English logo, long-distance throttle controller shipped with the vehicle (only electronic control engine) | |
| Upbody | 10 | |
* Description:
1. Terms of payment: T/T, 30% deposit, balance before delivery from factory.
2. Delivery at China port period: 55 working days after advance payment.
3. Vehicle warranty period: 12 months from the date of bill of lading.
